防火吸音涂料K-13
Fireproof sound-absorbing coating K-13
产品简介：
Product Introduction:
都彭牌K-13防火吸音涂料喷涂，拥有独家核心技术。符合消防要求，部分性能超过同类进口产品，防潮防霉，抗冷凝，环保安全；降噪吸音系数接近吸音棉的效果。可满足吸音、保温、隔音的要求。产品特性：适用于室内建筑物等的表面：游泳馆和其他体育场馆、飞机场侯机楼、电 梯井、地铁、地下大型停车场，火车站，汽车站，车站站台，候车室，钢结构场所、地下室，博物馆、音乐厅、商场超市、歌剧院、图书馆、隧道、卡拉OK、道路隔音屏障、别墅、高档住宅、酒店、学校、工厂，等室内墙身装饰。吸音性能强大，并有效地减少和缓解噪音，效果极佳。由环保 纤维、丙烯酸乳液及助剂组成。具有极佳的附着力，优良的保色性及抗老化性，独特配方，提供防 霉抗藻、抗碱、抗紫外线辐射等诸多功能。
The Duzhipeng brand K-13 fireproof sound-absorbing coating, with its exclusive core technology, meets fire safety requirements and surpasses similar imported products in certain performance aspects. It is moisture-resistant, mold-proof, anti-condensation, environmentally friendly, and safe. Its noise reduction and sound absorption coefficient is close to that of sound-absorbing cotton. It can fulfill the requirements of sound absorption, thermal insulation, and sound insulation. Product characteristics: suitable for surface decoration of indoor buildings such as swimming pools and other sports venues, airport terminals, elevator shafts, subways, underground parking lots, train stations, bus stations, train platforms, waiting rooms, steel structure places, basements, museums, concert halls, shopping malls and supermarkets, opera houses, libraries, tunnels, karaoke bars, road noise barriers, villas, high-end residences, hotels, schools, factories, and other indoor walls. It has strong sound absorption performance and effectively reduces and mitigates noise, achieving excellent results. Composed of environmentally friendly fibers, acrylic emulsion, and additives, it boasts excellent adhesion, superior color retention, and anti-aging properties. Its unique formula provides various functions such as mold and algae resistance, alkali resistance, and UV radiation resistance.
|
产品特性：
Product Features
K-13防火吸音涂料喷涂是一种新型环保建筑涂料，主要由混合环保纤维与水性乳液组成，经拌和后通过空压泵进行喷涂，与雾化水混合喷到需要保护的基材上形成涂层。该涂层可满足吸音、保温的要求。
K-13 fireproof sound-absorbing coating spraying is a new type of environmentally friendly architectural coating, primarily composed of mixed environmentally friendly fibers and water-based lotion. After mixing, it is sprayed through an air pressure pump and mixed with atomized water onto the substrate to be protected, forming a coating layer. This coating layer meets the requirements for sound absorption and thermal insulation.
K-13防火吸音涂料喷涂层性能与指标:
Performance and indicators of K-13 fireproof sound-absorbing coating spray layer:
名 称 name |
单位 unit |
检验值 test value |
检验依据 Inspection basis |
燃烧性能 combustion performance |
级 Grade |
A级以上 Grade A and above |
GB 8624-2012 |
吸音系数 sound absorption coefficient |
NRC(2.5～5cm) |
≥0.7～0.9 |
GB/ T20247-2006 |
施工简介：
Construction Brief:
1. 基层必须是干净的混凝土或者物体的表面，尤其应注意不能有漏水痕迹。不可在基层上留有油污。地上一层需做好防水及打地面工程，以免渗漏造成脱落。如原基面已经损坏或有严重裂缝，应先进行修补。对门窗及各种设备、管线和非喷涂部位防护遮挡，堵塞非喷涂部位及通风管线、孔。清理工作面的障碍物，保证喷涂手的顺畅移动空间及其安全性，保持最佳喷射距离。可一次喷涂完成25mm以上。喷涂层表面整形：待喷涂产品表面干燥约半小时后，根据吸声工程的不同要求，使用压板或铝合金杠尺等不同整形工具进行表面整形。
1. The base layer must be a clean concrete or object surface, with particular attention paid to the absence of water leakage traces. No oil stains are allowed on the base layer. The ground floor requires proper waterproofing and flooring works to prevent detachment caused by leakage. If the original base surface is damaged or has severe cracks, it should be repaired first. Protect and block doors, windows, various equipment, pipelines, and non-spraying areas, and block non-spraying areas, ventilation pipelines, and holes. Clear obstacles on the working surface to ensure smooth movement space and safety for the spraying operator, and maintain the optimal spraying distance. It is possible to complete spraying in one go for distances exceeding 25mm. Surface shaping of the spraying layer: After the surface of the spraying product dries for about half an hour, use different shaping tools such as pressure plates or aluminum alloy straightedges to shape the surface according to different requirements of sound absorption engineering.
2. 在整形后的产品表面再次喷涂粘接剂，增强表面强度。掌握喷涂顺序，防止角隅处及檩条背面出现空洞或疏松。喷涂后的纤维吸音层应保持良好的通风、干燥维护，固化72小时后可进行修整、装饰等其他工序。喷涂后的施工现场应及时清理，将回弹料及落地料装袋清除现场。
2. Apply adhesive to the surface of the reshaped product again to enhance its surface strength. Master the spraying sequence to prevent voids or looseness at corners and on the back of purlins. The fiber sound-absorbing layer after spraying should be maintained in good ventilation and dryness. After curing for 72 hours, other processes such as finishing and decoration can be carried out. The construction site after spraying should be cleaned up in a timely manner, and rebound materials and fallen materials should be bagged and removed from the site.
施工方法：施工前准备→成品保护→喷涂基面处理→喷涂施工→表面修整→喷涂场地清理→质量验收→喷涂层自然养护。
Construction method: Preparation before construction → finished product protection → spraying base surface treatment → spraying construction → surface finishing → spraying site cleaning → quality acceptance → natural curing of spraying layer.
其它事项：施工流程及技术要点(参考发布公开的资料，要根据各地具体情况，灵活采用。)
Other matters: construction procedures and technical key points (Refer to publicly released materials, and adapt flexibly according to specific local conditions.)
声学要求： 符合 GBJ 47-1983 和 GB/T 16731-2023国家标准；符合GB/ T20247-2006/ISO 354:2003 国家标准。
Acoustic requirements: Comply with national standards GBJ 47-1983 and GB/T 16731-2023; comply with national standards GB/T 20247-2006/ISO 354:2003.
防火性能： 符合 GB 8624-2012 国家标准。
Fire resistance: Complies with the national standard GB 8624-2012
环保性能： 符合 GB30981.1-2025《涂料中有害物质限量 第1部分：建筑涂料》国家标准。
Environmental performance: Complies with the national standard GB30981.1-2025 "Limit of Harmful Substances in Coatings - Part 1: Architectural Coatings".
